Self Contained Exposure Unit
Product Name : Self Contained Exposure Unit
Product Model : MT-120 / MT-150
- FUNCTIONS
- SPECIFICATIONS
- SAMPLES
This Self Contained screen exposure unit is designed for exposing operations for emulsion coated screen frame which is attached to the positive film. The light source is employed with 3000W Ultraviolet light offering uniform, excellent exposure results.
| MODEL | MT-120 | MT-150 |
|---|---|---|
| MAXIMUM SIZE OF FRAME | 700 x 1000 mm | 1000 x 1300 mm |
| EXPOSURE TABLE SIZE ( L x W ) | 900 x 1200 mm | 1200 x 1500 mm |
| POWER | 220V 3KW 30A. | 220V 3KW 30A. |
| LIGHT SOURCE | 3000W | 3000W |
| MACHINE DIMENSIONS | 1100 x 1300 x 1200 mm | 1400 x 1600 x 1200 mm |
| WEIGHT | 230 kgs | 300 kgs |
＊ Customized specifications are available.
